Dwyer 608-10B Intrinsically Safe Differential Pressure Transmitter
$1,724$2,069 (-17%)
Dwyer 608-10B is an intrinsically safe differential pressure transmitter with an impressive temperature range of -20 to 185°F. It offers ±0.5% or ±0.25% full scale accuracy, a quick response time of 250 ms, and a durable NEMA 4X enclosure rating. Powered by 12-30 VDC, it has screw terminal electrical connections and…
Dwyer 608-10B is an intrinsically safe differential pressure transmitter with an impressive temperature range of -20 to 185°F. It offers ±0.5% or ±0.25% full scale accuracy, a quick response time of 250 ms, and a durable NEMA 4X enclosure rating. Powered by 12-30 VDC, it has screw terminal electrical connections and outputs a 4-20 mA DC signal. The transmitter is ideal for clean/dry air and compatible combustible gases. With a pressure limit of 100 psig and 15 psid, it accommodates various applications. Its thermal effect is ±0.02% F.S./°F for 0.5% accuracy and ±0.01% F.S./°F for 0.25% accuracy. The transmitter is not position sensitive and provides stability of ±0.5% F.S./yr.
Specifications
| Component | Differential Pressure Transmitter |
|---|---|
| (Instrument-Sensor) Measurement Accuracy | 0.25% |
| (Instrument-Sensor) NEMA Protection | NEMA 4X |
| (Instrument-Sensor) IP Protection | IP65 |
| (Instrument-Sensor) Application | Gas |
| (Instrument-Sensor) Supply Voltage | 12-30 VDC |
| (Instrument-Sensor) Type | Intrinsically Safe Differential |
| (Instrument-Sensor) Application | Air |
| (Instrument-Sensor) Temperature Range | -20 – 185°F/-28 – 85°C |
| (Instrument-Sensor) Measurement Accuracy | 0.50% |
| Manufacturer | Dwyer Instruments |
Features
High accuracy at low pressure ranges provides exceptional measurement for ensuring tight-control and minimizing costly out of specification conditions
Intrinsically safe for use in the specified hazardous locations meets specifications where pressure transmission and safety cannot be compromised
NEMA 4X rated enclosure provides protection in harsh environments permitting outdoor monitoring or in areas where dust and particulate matter exists
