Dwyer ACT-MI07-12VDC Pneumatic/Electric Actuator
$5,344$6,412 (-17%)
Dwyer ACT-MI07-12VDC is a pneumatic and electric actuator designed for hazardous locations. It has a temperature range of -40 to 140°F and power options of 110 VAC, 220 VAC, 24 VAC, or 24 VDC. It has a NEMA 7 enclosure rating and features 1/2″ female NPT electrical connections. The actuator is made from powder coated…
Dwyer ACT-MI07-12VDC is a pneumatic and electric actuator designed for hazardous locations. It has a temperature range of -40 to 140°F and power options of 110 VAC, 220 VAC, 24 VAC, or 24 VDC. It has a NEMA 7 enclosure rating and features 1/2" female NPT electrical connections. The actuator is made from powder coated aluminum and has a maximum supply pressure of 120 psi. It comes with a position indicator, two limit switches, and conforms to NAMUR standard for accessory mounting.
Specifications
| (Instrument-Sensor) Supply Voltage | 24 VDC |
|---|---|
| (Instrument-Sensor) NEMA Protection | NEMA 7 |
| (Instrument-Sensor) Supply Voltage | 24 VAC |
| (Instrument-Sensor) Supply Voltage | 110 VAC |
| Component | Actuator |
| (Instrument-Sensor) Hazardous Location Class | Class I – Group C & D; Class II – Group E-G; Division I & II |
| (Instrument-Sensor) Temperature Range | -40 – 140°F/-40 – 60°C |
| Sub Component | Pneumatic/Electric Actuator |
| (Instrument-Sensor) Supply Voltage | 220 VAC |
| Manufacturer | Dwyer Instruments |
Features
ISO 5211 Mounting configuration for easy installation
Pneumatic actuators offer corrosion resistance anodized finish
NAMUR mounting configuration on pneumatic actuators
Two-position electric actuators include auxiliary limit switches
Modulating electric actuators offer an output for position monitoring
