Dwyer ACT-MI08-110VAC Pneumatic/Electric Actuator
$5,978$7,173 (-17%)
Dwyer ACT-MI08-110VAC Pneumatic and Electric Actuator is a versatile solution for hazardous locations. With a temperature range of -40 to 140°F and power options of 110VAC, 220VAC, 24VAC, or 24VDC, it meets a variety of needs. It features a NEMA 7 enclosure rating and standard features including a position indicator…
Dwyer ACT-MI08-110VAC Pneumatic and Electric Actuator is a versatile solution for hazardous locations. With a temperature range of -40 to 140°F and power options of 110VAC, 220VAC, 24VAC, or 24VDC, it meets a variety of needs. It features a NEMA 7 enclosure rating and standard features including a position indicator and two limit switches. The DA series is double-acting and the SR series is spring return, with maximum supply pressures of 120 psi and 80 psi respectively. It also includes convenient features such as accessory mounting, modulating input, and various connection sizes.
Specifications
| (Instrument-Sensor) Supply Voltage | 24 VDC |
|---|---|
| (Instrument-Sensor) NEMA Protection | NEMA 7 |
| (Instrument-Sensor) Supply Voltage | 24 VAC |
| (Instrument-Sensor) Supply Voltage | 110 VAC |
| Component | Actuator |
| (Instrument-Sensor) Hazardous Location Class | Class I – Group C & D; Class II – Group E-G; Division I & II |
| (Instrument-Sensor) Temperature Range | -40 – 140°F/-40 – 60°C |
| Sub Component | Pneumatic/Electric Actuator |
| (Instrument-Sensor) Supply Voltage | 220 VAC |
| Manufacturer | Dwyer Instruments |
Features
ISO 5211 Mounting configuration for easy installation
Pneumatic actuators offer corrosion resistance anodized finish
NAMUR mounting configuration on pneumatic actuators
Two-position electric actuators include auxiliary limit switches
Modulating electric actuators offer an output for position monitoring
