Dwyer DSGT-102-C1S Digital Indicating Transmitter
$1,814$2,177 (-17%)
Dwyer DSGT-102-C1S is a digital indicating transmitter suitable for temperature monitoring in a range of 14 to 140ºF (-10 to 60ºC). With an accuracy of 0.25% FS, it operates on 12 to 36 VDC power and has a quick response time of 100 ms. Its fiberglass reinforced thermoplastic case ensures durability, and the 3 ft…
Dwyer DSGT-102-C1S is a digital indicating transmitter suitable for temperature monitoring in a range of 14 to 140ºF (-10 to 60ºC). With an accuracy of 0.25% FS, it operates on 12 to 36 VDC power and has a quick response time of 100 ms. Its fiberglass reinforced thermoplastic case ensures durability, and the 3 ft flying leads provide easy electrical connections. The output signal is 4 to 20 mA, making it compatible with non-combustible liquids and gases. The 5-digit display is easily readable with a 0.88" height. The wetted materials consist of a 17 to 4 stainless steel sensor with a 316 SS socket. It has a pressure limit of 2 x FS range and a 1/2" male NPT process connection. Set point adjustment is possible through menu selections, and it has a thermal effect of 0.04% FS/°F. The loop resistance for this transmitter is 0 to 1090 Ω max. It operates on (2) C alkaline batteries, which are user replaceable.
Specifications
| (Instrument-Sensor) Measurement Accuracy | 0.25% |
|---|---|
| (Instrument-Sensor) Supply Voltage | 12-36 VDC |
| (Instrument-Sensor) Application | Liquid |
| (Instrument-Sensor) Application | Gas |
| (Instrument-Sensor) Temperature Range | 14 – 140°F/-10 – 60°C |
| Component | Digital Indicating Transmitter |
| Manufacturer | Dwyer Instruments |
Features
All-in-one digital gage package is designed to reduce installation costs, instrument cost, and save space where an application requires a gage, transmitter, and switches
Durable fiberglass reinforced thermoplastic case to meet NEMA 4 (IP56) requirements supports use in harsh environments
Password protected calibration and disable functions helps to insure no errors by untrained personnel
