Dwyer DSGT-119-C2S Digital Indicating Transmitter
$2,939
Dwyer DSGT-119-C2S is a digital indicating transmitter that accurately measures temperature from 14 to 140ºF (-10 to 60ºC). It has a 0.25% FS accuracy and operates on a power requirement of 12 to 36 VDC. The transmitter features a 5 digit display, 4 to 20 mA output signal, and a response time of 100 ms. It is designed…
Dwyer DSGT-119-C2S is a digital indicating transmitter that accurately measures temperature from 14 to 140ºF (-10 to 60ºC). It has a 0.25% FS accuracy and operates on a power requirement of 12 to 36 VDC. The transmitter features a 5 digit display, 4 to 20 mA output signal, and a response time of 100 ms. It is designed for use with compatible non-combustible liquids and gases. The transmitter is equipped with a fiberglass reinforced thermoplastic case, 3 ft flying leads for electrical connections, and a 1/2" male NPT process connection. It has a pressure limit of 2 x FS range and an adjustable set point through menu selections. The wetted material consists of 17 to 4 stainless steel sensor and 316 SS socket. It has a thermal effect of 0.04% FS/°F and a loop resistance of 0 to 1090 Ω max. The transmitter is powered by (2) C alkaline batteries which are user replaceable.
Specifications
| (Instrument-Sensor) Measurement Accuracy | 0.25% |
|---|---|
| (Instrument-Sensor) Supply Voltage | 12-36 VDC |
| (Instrument-Sensor) Application | Liquid |
| (Instrument-Sensor) Application | Gas |
| (Instrument-Sensor) Temperature Range | 14 – 140°F/-10 – 60°C |
| Component | Digital Indicating Transmitter |
| Manufacturer | Dwyer Instruments |
Features
All-in-one digital gage package is designed to reduce installation costs, instrument cost, and save space where an application requires a gage, transmitter, and switches
Durable fiberglass reinforced thermoplastic case to meet NEMA 4 (IP56) requirements supports use in harsh environments
Password protected calibration and disable functions helps to insure no errors by untrained personnel
