Dwyer OP-P-2 Orifice Plate Flowmeter
$3,617$4,341 (-17%)
Dwyer OP-P-2 Orifice Plate Flowmeter is a reliable and accurate solution for measuring the flow of compatible liquids and gases. With a temperature range of -50 to 200°F (-45 to 93°C) and an accuracy of ±0.6% full scale flow, this flowmeter provides precise measurements. It features a 304 SS wetted material…
Dwyer OP-P-2 Orifice Plate Flowmeter is a reliable and accurate solution for measuring the flow of compatible liquids and gases. With a temperature range of -50 to 200°F (-45 to 93°C) and an accuracy of ±0.6% full scale flow, this flowmeter provides precise measurements. It features a 304 SS wetted material construction and Buna-N gaskets for durability. The flowmeter has a pressure limit of 150 psi and a process connection of 1/4" female NPT, suitable for line sizes ranging from 1/2" to 24". Installation is quick and easy, using standard flange 125#/150# ratings. The head loss is calculated using the Beta ratio, with pipe requirements of 10 diameter upstream and 5 diameter downstream.
Specifications
| (Instrument-Sensor) Application | Liquid |
|---|---|
| (Instrument-Sensor) Application | Gas |
| Component | Flow Meter |
| (Instrument-Sensor) Type | Orifice Plate |
| (Instrument-Sensor) Measurement Accuracy | 0.60% |
| (Instrument-Sensor) Temperature Range | -50 – 200°F/-45 – 93°C |
| Manufacturer | Dwyer Instruments |
Features
Mounted with standard flanges with no need of specialty flanges
Reduced installation costs with simple installation by slipping the unit between standard flanges
Easy access with corner type metering taps
Long operation life with corrosion free material
Stainless steel wetted parts assures long term reliability and accuracy
Proven through a wide range of applications for energy efficiency
