Dwyer TR-7-ABXL Safe-T-Ground
$2,880$3,456 (-17%)
Dwyer TR-7-ABXL Safe-T-Ground is an explosion-proof enclosure designed for hazardous locations. It has a temperature range of -13 to 104°F and a power requirement of 105-125 VAC 60 Hz. The housing is made of 356-T6 cast aluminum alloy, and the electrical rating is DPDT, 10 amps, 125 VAC, 60 Hz. It has a 3/4″ NPT…
Dwyer TR-7-ABXL Safe-T-Ground is an explosion-proof enclosure designed for hazardous locations. It has a temperature range of -13 to 104°F and a power requirement of 105-125 VAC 60 Hz. The housing is made of 356-T6 cast aluminum alloy, and the electrical rating is DPDT, 10 amps, 125 VAC, 60 Hz. It has a 3/4" NPT conduit connection, and the dimensions are 6-5/8" W x 10-3/8" H x 5-5/8" D. Installation is done using 7/16" mounting lugs, and wiring is done via a terminal strip. The package includes 2 grounding studs, but additional pairs can be ordered. The contactor is a grounding clamp made of molded polyethylene with beryllium copper contact clips. The product also includes a 16-2 type SO coiled cable that retracts to 3' and extends to 16'.
Specifications
| Component | Ground Control |
|---|---|
| (Instrument-Sensor) Temperature Range | -13 – 104°F/-25 – 40°C |
| (Instrument-Sensor) Supply Voltage | 105-125 VAC |
| (Instrument-Sensor) Supply Voltage | 220-240 VAC |
| Manufacturer | Dwyer Instruments |
Features
Audible alarm and LED status indicators
Explosion-proof housing
