Eaton A202K6BEM 400A Magnetically Held Lighting Contactor, 600V

The Eaton A202K6BEM is a magnetically held (magnetically latched) lighting contactor from Eaton’s A202 series. Rated for 400 A switching and specified for up to 600 V AC at 60 Hz, this 2-pole lighting contactor is purpose-built for industrial and commercial lighting control, ballast switching and other resistive load applications where reliable maintained switching is required.

Key Features

• Engineered and tested specifically for lighting and resistive loads for reliable ballast and lamp switching.
• Magnetically held (latched) design provides maintained contact position without continuous coil power.
• High current switching capability — 400 A rating with a 600 V AC maximum system rating at 60 Hz.
• Two-pole configuration ideal for switching multi-conductor lighting circuits and phase control.
• Standard 1 NO auxiliary contact (10 A rating for two- and three-pole units); top and side-mounted auxiliaries available; straight-through wiring for easier installation.
• Compatible with Eaton Freedom snap-on accessories for flexible field configuration.

Technical Specifications

Applications

Common uses include commercial and industrial lighting panels, ballast/HID/LED switching, street and area lighting control, and large facility lighting circuits requiring maintained switching.

We supply genuine Eaton products through authorized channels from our Batam base, delivering across Indonesia and Southeast Asia. Competitive lead times and local support — contact us to request a quotation or check stock availability.
