Eaton ECL04H1A3A 400A Lighting Contactor, 120V, 3-Pole, NEMA 1
$45,540$54,649 (-17%)
Eaton ECL04H1A3A A202 magnetically latched lighting contactor — 400 A rated, 120 VAC coil, 3-pole in NEMA 1 painted-steel enclosure. Genuine Eaton unit supplied by Wulan Dari with fast delivery across Indonesia and Southeast Asia.
The Eaton ECL04H1A3A (A202 series) is a magnetically latched lighting contactor engineered for heavy-duty lighting and resistive load switching. Rated 400 A with a 120 VAC control coil and three poles in a NEMA 1 painted-steel enclosure, this IEC/NEMA-style lighting contactor suits commercial and industrial lighting distribution, central lighting panels, and large resistive circuits where reliable, high-current switching is required.
Key Features
- Designed and tested specifically for lighting and resistive loads for reliable service in luminaires and heaters.
- Magnetically latched A202 series design; non-combination mechanically held and magnetically latched configuration per Eaton specification.
- High continuous carry capacity — 400 A three-pole configuration for central lighting and heavy resistive circuits.
- 120 VAC coil standard for easy integration with common control circuits and building automation systems.
- Standard 1 NO auxiliary contact included; top and side-mounted auxiliary options available for expanded control and signaling.
- Painted-steel NEMA 1 enclosure with straight-through wiring and snap-on accessory support for quick installation and maintenance.
Technical Specifications
| Manufacturer | Eaton |
|---|---|
| Commercial Reference | ECL04H1A3A |
| Series | A202 |
| Component | Lighting Contactor |
| Rated Current | 400 A |
| Starter Coil Voltage | 120 VAC |
| Starter Enclosure Type | NEMA 1 (painted steel) |
| Poles | 3 Pole |
| Auxiliary Contacts | Standard 1 NO; top/side-mounted auxiliaries available |
| Latch Type | Magnetically latched (A202 series); non-combination mechanically held/magnetically latched |
Applications
Central commercial lighting panels, stadium and large-area illumination, industrial resistive load switching, emergency lighting systems, and building automation lighting control.
We supply genuine Eaton contactors through authorized distribution. Based in Batam, Wulan Dari delivers across Indonesia and Southeast Asia with competitive lead times. Contact us for stock confirmation and request a quotation today to secure your Eaton ECL04H1A3A lighting contactor.
