Eaton V211K5CJZ1 270A NEMA Reversing Vacuum Contactor, 3-Pole
$39,141$46,969 (-17%)
Eaton V211K5CJZ1 NEMA reversing vacuum contactor, 270 A rating (Size 5). Genuine Eaton part for heavy motor reversing and control — available from Batam with fast delivery across Indonesia and Southeast Asia.
Eaton V211K5CJZ1 is a NEMA reversing vacuum contactor (Size 5, horizontal) rated 270 A with a maximum motor rating of 75 HP at 200 V and a 110/120 V AC control coil. Built for heavy motor control and reversing duties, this vacuum contactor delivers reliable, quiet switching for motor control centers, industrial drives, conveyors, pumps and compressors where compact NEMA contactor form factors and long service life are needed.
Key Features
- Rated for 270 A continuous switching in a Size 5 vacuum contactor frame.
- Maximum motor capacity up to 75 HP at 200 V for demanding loads.
- 110/120 V AC control coil standard for common control systems.
- Horizontal mounting configuration with removable line and load lugs for easy wiring.
- Available electrical and mechanical interlocks to support reversing starter arrangements.
- Rugged, compact and lightweight construction with quiet operation and long service life.
Technical Specifications
| Manufacturer | Eaton |
|---|---|
| Commercial Reference | V211K5CJZ1 |
| Component | Vacuum Contactor (NEMA reversing contactor) |
| Frame / Size | Size 5 |
| Orientation | Horizontal |
| Rated Current | 270 Amp |
| Maximum Hp Rating | 75 HP @ 200 V |
| Control Coil Voltage | 110/120 V AC |
| Line & Load Lugs | Removable |
| Interlocks | Electrical and mechanical interlocks available |
Applications
Used for reversing and starting large AC motors on pumps, compressors and fans; integration into motor control centers (MCCs) and industrial drives; conveyor drive control in manufacturing and material handling; heavy industry installations such as paper, steel and mining where robust vacuum switching is required.
We supply genuine Eaton parts through authorized channels from our Batam base, offering fast delivery across Indonesia and Southeast Asia. Contact us for competitive lead times and to request a quotation for the V211K5CJZ1 vacuum contactor.
