Omega HX86BA HIGH TEMP (120C) RH TX
$2,296
Relative Humidity/Temperature/Barometric Pressure Transmitter, 0 % to 100 %, -40 °C to 120 °C, 750 mb to 1100 mb BP, 18 Vdc to 30 Vdc, 4 mA to 20 mA, Relays, RS232 Output, HX80A Series, Each
Relative Humidity/Temperature/Barometric Pressure Transmitter, 0 % to 100 %, -40 °C to 120 °C, 750 mb to 1100 mb BP, 18 Vdc to 30 Vdc, 4 mA to 20 mA, Relays, RS232 Output, HX80A Series, Each
Specifications
| Conditioner Output Signal Range | 4-20 Ma |
|---|---|
| Manufacturer | Omega Engineering |
| Component | Relative Humidity/Temperature/Barometric Pressure Transmitter |
| Conditioner Supply Voltage | 18-30 Vdc |
Features
316 SS Housing
± 1% RH Accuracy
± 0.5°C (1.0°F) Temperature Accuracy
High Temperature [120°C (248°F)]
Accuracy± 0.5 °C (± 0.9 °F)
Cable Length1.8 m
Data InterfaceRS232
Data Interface NoteRS232C (bi-directional) to DTE device, 19.2 kilo baud, 8 bits data, 1 stop bit, no parity
FilterSinter Stainless Steel
Current, Max50 mA
Pressure LimitsUp to 690 psi
Pressure Note317 kg (700 lb) (47.6 bar)
Probe Diameter19 mm
Probe Length203 mm
Process Connection Size3/4 in
Process Connection TypeNPT Male and Female
Relative Humidity5 to 95%
Relative Humidity Accuracy± 1.0 % RH
Sensor MaterialStainless Steel
Supply Voltage18 to 30 Vdc
Temperature Measurement, Max120 °C
Temperature Measurement, Min-20 °C
Time Constant<15 sec, air flow dependent (for 66.6% response)
Weight0.9 kg
